• Eltima Virtual Serial Port Driver creates any number of virtual serial ports in your system and connects them into pairs via virtual null modem cable. You can create as many virtual serial ports in your system as possible to fit your needs.

  • File Name:evspd.exe
  • Author:ELTIMA Software GmbH

  • License:Shareware ($99.95)
  • File Size:3.04 Mb

  • Runs on:Win98, WinME, WinNT 4.x, WinXP, Windows2000, Windows2003

• Virtual Serial Ports Driver XP creates two pure virtual serial ports in your system which are virtually connected to each other. For other Windows applications, virtual ports will be seen exactly as two real serial ports connected via null-modem. ...

  • File Name:vspdxpd.exe
  • Author:ELTIMA Software GmbH

  • License:Shareware ($111.95)
  • File Size:1.2 Mb

  • Runs on:Win 98, ME, NT 4.x, XP, 2000

• Virtual Serial Ports Driver (VSPD) creates two pure virtual serial ports in your system which are virtually connected to each other. For other Windows applications, virtual ports will be seen exactly as two real serial ports connected via null-modem. ...

  • File Name:evspdxp.exe
  • Author:ELTIMA Software GmbH

  • License:Shareware ($111.95)
  • File Size:3 Mb

  • Runs on:Windows All

• Virtual Serial Port Driver by Eltima creates virtual COM port pairs in the system. Using these ports serial applications can communicate with each other and transfer data via virtual null-modem cable.

  • File Name:vspd2.exe
  • Author:Eltima Software

  • License:Shareware ($139.95)
  • File Size:5.33 Mb

  • Runs on:Win2000, WinXP, WinVista, WinVista x64, Win7 x32, Win7 x64, Windows2003, Windows 8, Windows 7, Windows 10, Windows Server 2012, Windows Server 2016

• Virtual Serial Port Driver XP4 creates two pure virtual serial ports in your system which are virtually connected to each other. For other Windows applications, virtual ports will be seen exactly as two real serial ports connected via null-modem. ...

  • File Name:vspdxp.exe
  • Author:ELTIMA Software GmbH

  • License:Shareware ($111.95)
  • File Size:1.47 Mb

  • Runs on:Win95, Win98, WinME, WinXP, WinNT 4.x, Windows2000

• VSPD Mobilel can create up to 20 pure virtual serial ports in your mobile system, resulting in 10 virtual serial ports pairs available for integration. Both ports in a pair are connected via a virtual null-modem and fully emulate real serial ports.

  • File Name:mobile_vspd.exe
  • Author:ELTIMA Software GmbH

  • License:Shareware ($49.95)
  • File Size:4.09 Mb

  • Runs on:Windows CE, Pocket PC, Windows Mobile 2003, Windows Mobile 2005

• Virtual Serial Ports Driver (VSPD) is a Windows device driver. Using it you can create any number of virtual serial COM ports in your system which will be virtually connected to each other. For example, after installing VSPD, you will have Virtual. ...

  • File Name:vspdxp.exe
  • Author:MKS Software

  • License:Shareware ($99.95)
  • File Size:650 Kb

  • Runs on:Win NT 3.x, NT 4.x, XP, 2000

• Virtual Serial Ports Driver for Windows CE creates two pure virtual serial ports in your system which are virtually connected to each other. For other Windows applications they are seen exactly as two real serial ports with null-modem connection.

  • File Name:vspdce.exe
  • Author:ELTIMA Software GmbH

  • License:Shareware ($49.95)
  • File Size:432 Kb

  • Runs on:Windows

• Eltima Virtual Serial Ports Driver XP creates any number of virtual serial ports in your system and connects them into pairs via virtual null modem cable. You can create as many virtual serial ports in your system as possible to fit your needs.

  • File Name:evspdxp.exe
  • Author:Virtual Rs232 Software

  • License:Shareware ($99.95)
  • File Size:1.84 Mb

  • Runs on:Windows

• Virtual Serial Ports Driver (VSPD) is a Windows device driver. Using it you can create two virtual serial COM ports in your system which will be virtually connected to each other. For example, after installing VSPD, you will have Virtual Serial Port. ...

  • File Name:vspd.exe
  • Author:SoftInfinity

  • License:Demo ($139.00)
  • File Size:

  • Runs on:Win95, Win98, WinME

• This is a non-official driver, written in C, for the FPS200 Veridicom's fingerprint sensor with the USB interface. It is also compatible with the Fujitsu's MBF200 fingerprint capture. ...

  • File Name:fps200usbdriver-1-0-0.tar.gz
  • Author:fps200usbdriver

  • License:Freeware (Free)
  • File Size:28 Kb

  • Runs on:BSD; Linux

• A driver for USB devices that use the KL5KUSB101 USB to Ethernet 1-Chip Controller. Written for the Netgear EA101..

  • File Name:kaweth-0.2.3.tar.gz
  • Author:kaweth

  • License:Freeware (Free)
  • File Size:13 Kb

  • Runs on:BSD; Linux

This page contains drivers for Serial On USB Port (COM3) manufactured by Targus Group Int™. Please note we are carefully scanning all the content on our website for viruses and trojans. This and other USB drivers we're hosting are 100% safe. Vendor: Targus Group Int™ Device: Serial On USB Port (COM3). Up until 2009, a few devices based on DisplayLink technology included an auto install driver feature. This required the DisplayLink USB driver to switch the device from being a mass storage device to a video device. Find & download drivers & user guides for Targus products like docking stations, USB hubs, mice, keyboards & more. Search by model name & serial number or browse by product type.

Related:Targus Usb Serial Driver - Targus Usb To Serial - Targus Usb Serial
-->

Versions supported

• Windows 10
• Windows 8.1

Applies to

• Device manufacturers of CDC Control devices

Microsoft-provided in-box driver (Usbser.sys) for your Communications and CDC Control device.

In Windows 10, the driver has been rewritten by using the Kernel-Mode Driver Framework that improves the overall stability of the driver.

• Improved PnP and power management by the driver (such as, handling surprise removal).
• Added power management features such as USB Selective Suspend.

In addition, UWP applications can now use the APIs provided by the new Windows.Devices.SerialCommunication namespace that allow apps to talk to these devices.

Usbser.sys installation

Load the Microsoft-provided in-box driver (Usbser.sys) for your Communications and CDC Control device.

Note

If you trying to install a USB device class driver included in Windows, you do not need to download the driver. They are installed automatically. If they are not installed automatically, contact the device manufacturer. For the list of USB device class driver included in Windows, see USB device class drivers included in Windows.

Windows 10

In Windows 10, a new INF, Usbser.inf, has been added to %Systemroot%Inf that loads Usbser.sys as the function device object (FDO) in the device stack. If your device belongs to the Communications and CDC Control device class, Usbser.sys is loaded automatically.You do not need to write your own INF to reference the driver. The driver is loaded based on a compatible ID match similar to other USB device class drivers included in Windows.

USBClass_02

USBClass_02&SubClass_02

• If you want to load Usbser.sys automatically, set the class code to 02 and subclass code to 02 in the Device Descriptor. For more information, see USB communications device class. With this approach, you are not required to distribute INF files for your device because the system uses Usbser.inf.
• If your device specifies class code 02 but a subclass code value other than 02, Usbser.sys does not load automatically. Pnp Manager tries to find a driver. If a suitable driver is not found, the device might not have a driver loaded. In this case, you might have to load your own driver or write an INF that references another in-box driver.
• If your device specifies class and subclass codes to 02, and you want to load another driver instead of Usbser.sys, you have to write an INF that specifies the hardware ID of the device and the driver to install. For examples, look through the INF files included with sample drivers and find devices similar to your device. For information about INF sections, see Overview of INF Files.

Note

Microsoft encourages you to use in-box drivers whenever possible. On mobile editions of Windows, such as Windows 10 Mobile, only drivers that are part of the operating system are loaded. Unlike desktop editions, it is not possible to load a driver through an external driver package. With the new in-box INF, Usbser.sys is automatically loaded if a USB-to-serial device is detected on the mobile device.

Windows 8.1 and earlier versions

In Windows 8.1 and earlier versions of the operating system, Usbser.sys is not automatically loaded when a USB-to-serial device is attached to a computer. To load the driver, you need to write an INF that references the modem INF (mdmcpq.inf) by using the Include directive. The directive is required for instantiating the service, copying inbox binaries, and registering a device interface GUID that applications require to find the device and talk to it. That INF specifies 'Usbser' as a lower filter driver in a device stack.

The INF also needs to specify the device setup class as Modem to use mdmcpq.inf. Under the [Version] section of the INF, specify the Modem and the device class GUID. for details, see System-Supplied Device Setup Classes.

For more information, see this KB article.

Configure selective suspend for Usbser.sys

Starting in Windows 10, Usbser.sys supports USB Selective Suspend. It allows the attached USB-to-serial device to enter a low power state when not in use, while the system remains in the S0 state. When communication with the device resumes, the device can leave the Suspend state and resume Working state. The feature is disabled by default and can be enabled and configured by setting the IdleUsbSelectiveSuspendPolicy entry under this registry key:

To configure power management features of Usbser.sys, you can set IdleUsbSelectiveSuspendPolicy to:

Targus Group Int Port Devices Drivers

• '0x00000001': Enters selective suspend when idle, that is, when there are no active data transfers to or from the device.

• '0x00000000': Enters selective suspend only when there are no open handles to the device.

That entry can be added in one of two ways:

• Write an INF that references the install INF and add the registry entry in the HW.AddReg section.

• Describe the registry entry in an extended properties OS feature descriptor. Add a custom property section that sets the bPropertyName field to a Unicode string, 'IdleUsbSelectiveSuspendPolicy' and wPropertyNameLength to 62 bytes. Set the bPropertyData field to '0x00000001' or '0x00000000'. The property values are stored as little-endian 32-bit integers.

  For more information, see Microsoft OS Descriptors.

Develop Windows applications for a USB CDC device

If you install Usbser.sys for the USB CDC device, here are the application programming model options:

Targus Group Int Port Devices Driver Updater

• Starting in Windows 10, a Windows app can send requests to Usbser.sys by using the Windows.Devices.SerialCommunication namespace. It defines Windows Runtime classes that can use to communicate with a USB CDC device through a serial port or some abstraction of a serial port. The classes provide functionality to discover such serial device, read and write data, and control serial-specific properties for flow control, such as setting baud rate, signal states.

• In Windows 8.1 and earlier versions, you can write a Windows desktop application that opens a virtual COM port and communicates with the device. For more information, see:

  Win32 programming model:

  • .NET framework programming model:

Targus Group Int Port Devices Driver

Related topics
